Rovi A3 MPS Mini Maxx
The Rovi A3 MPS Mini Maxx is an innovative highly adjustable stand up system. This wheelchair combines a power standing function with a full range of power positioning options.
Description
The Rovi A3 MPS Mini Maxx is an innovative highly adjustable stand up system. This wheelchair combines a power standing function with a full range of power positioning options. The Rovi A3 MPS Mini Maxx is a mid-wheel drive base with an outstanding combination of independence, accessibility and functionality.
Features
| Feature | Specification |
|---|---|
| CG Tilt | 45° |
| Recline with ESR* | 165° |
| Standing | Yes |
| Power Adjustable Seat Height | 7” (18cm) |
| Power Elevating Belt Drive Center Mount Articulated Foot Platform |
Yes |
* ESR Extended Shear Reduction
Specifications
| Feature | Specification |
|---|---|
| Suspension System | Active Ride Control (ARC) |
| Base Width | 25.5” (65cm) |
| Base Length | 36.5” (93cm) |
| Drive Wheel Size | 14” (35.5cm) |
| Caster Wheel Size (front/rear) | 6” (15cm) |
| Base only Turning Radius | 20.5” (52cm) |
| Drivetrain | 4-pole EAD Motors |
| Batteries | 2 x M34 |
| Battery Charger | 8A, Stand Alone |
| Range (1) | 28km (17.7 miles) |
| Base Weight (inc batteries) | 107kg (236lb) |
| Ground Clearance | 3” (7.5cm) |
| Maximum Speed w/MPS System | 9.3kmh (5.8mph) |
| Seat Width | 12”-17” (30-43cm) |
| Seat Depth | 12”-17” (30-43cm) |
| Seat-to-Floor | 7.5° Up / 7.5° Down |
| Weight Capacity | Up to 90kg (200lb) |
|
MPS System Weight (2)
|
95kg (210lb) |
(1) Actual driving range and speed may vary due to factors such as user weight, type and grade of
terrain, battery condition & charge level; type and condition of the drive wheels, and variations in the
drive and control systems.
(2) Actual weight will vary based on seating options selected
Brochure
Colour Options
Enquiry
Product Enquiry
"*" indicates required fields
Disclaimer
All product descriptions, indications or advice found on this website are to be used as a guide only, and are by no means a substitute for professional medical advice. Proper use of medical devices requires diagnosis by a physician or physical therapist. Urgoform accepts no responsibility for the improper or uninformed use of it’s products.
