Molift Duo Gantry Frame
Molift Duo Gantry Frame is a robust and flexible free-standing gantry system. Used when a fixed rail system is not an option, the Molift Duo Gantry Frame can be easily installed without the need of fixtures to an existing structure. A lifting capacity of up to 300 kg, the gantry frame can be used with Molift Nomad and Molift Air ceiling motors.
Description
Molift Duo Gantry Frame is a robust and flexible free-standing gantry system. Used when a fixed rail system is not an option, the Molift Duo Gantry Frame can be easily installed without the need of fixtures to an existing structure. A lifting capacity of up to 300 kg, the gantry frame can be used with Molift Nomad and Molift Air ceiling motors.
Features
- Versatile Solution: Catering to clients in rented accommodation or premises unsuitable for conventional ceiling hoist installations.
- Robust and Flexible Design: Sturdy and flexible free-standing gantry system, offering a lifting capacity of up to 300 kg.
- Choice of Length: Available in four lengths ranging from 2.0 m to 3.5 m, with height adjustability, ensuring suitability for various environments and applications.
- Compatibility: Compatible with Molift Nomad and Molift Air ceiling motors, enhancing versatility and functionality.
- Easy Assembly: Can be erected in minutes, providing basic rail functionality without the need for permanent installation.
- Durable Construction: Constructed with a sturdy aluminium frame and two posts, ensuring reliability and durability in long-term use.
Specifications
Specifications
Dimensions
- Height: 2250 – 2550 mm
- Depth: 1200 mm
- Transport height: 1700 mm
- Material: Anodized aluminium, plastic
Molift Duo 2000
- Overall width: 2150 mm
- Maximum internal width: 2000 mm
- Unit weight: 38 kg
Molift Duo 2500
- Overall width: 2650 mm
- Maximum internal width: 2500 mm
- Unit weight: 40 kg
Molift Duo 3000
- Overall width: 3150 mm
- Maximum internal width: 3000 mm
- Unit weight: 42 kg
Molift Duo 3500
- Overall width: 3650 mm
- Maximum internal width: 3500 mm
- Unit weight: 44 kg
Care Instructions
- Clean the product with a solvent-free cleaning agent with a pH level between 5–9, or with a 70% disinfectant solution
Safety
- Maximum lifting capacity: 300 kg
Manual
Brochure
Warranty & Standards
Warranty
- 2 years
- Expected Lifetime: 10 years
Compliance
- ARTG Number: 360015
- Australian Standards: 10535:2006
Enquiry
Product Enquiry
"*" indicates required fields
Disclaimer
All product descriptions, indications or advice found on this website are to be used as a guide only, and are by no means a substitute for professional medical advice. Proper use of medical devices requires diagnosis by a physician or physical therapist. Urgoform accepts no responsibility for the improper or uninformed use of it’s products.
